Pressure And
Temperature OIL
FOR ROTAX 912ULS (100HP) WITH 4..20mA
SENDER
Diameter: 57mm
Units : BAR & ºC
|
-
The
IM-3543 instruments have been designed
especially to measure the pressure and
Temperature Oil in Rotax® engines 912 ULS
(100CV).
-
The IM-3543
is available in 57 mm diameter.
-
A
TFT colour screen show the Oil Pressure and Oil
Temperature. The screen is readable at direct
sunlight.
-
The
instruments have been designed to work with both
12V and 24V systems.
-
The
minimum instrumentation requirements for
the BRP_ROTAX® four stroke engines include a
gauge for continuous Oil Pressure and
Temperature monitorization.
|
|
|
| Case |
Plastic |
| Weight |
125g |
| Suitable
for |
Rotax 912ULS with 4..20mA
sender and original VDO Temp. sender |
| Power
Supply |
10..30VDC |
| Power
Current |
0.15 Amp. Max. |
| Max.
Deviation |
1% |
|
Dimensions |
See sketch |
|
Calibration |
Calibrated by the
manufacturer prior to shipment. |
|
|
|
 |
|
|
 |
| |
|
|
|
|
|
|
|
